Holophane

SSA HLP Pole

Square Straight Aluminum Pole
    Buy America(n) Option AvailableBuy America(n) Option Available
  • Overview
  • Specifications
Pole shaft is one piece, 6005, 6061, or 6063-aluminum alloy, heat-treated to a T6 temper. Pole base shall be 356 or A356 aluminum alloy, heat-treated to a T6 temper after welding. Hand hole is 2” x 4” minimum, cover and fasteners are included. Nut covers shall be provided as standard. Finish shall match pole. Removable pole cap shall be provided with each drill pattern type pole. Anodized, painted, or satin brush finish. Painted poles shall be semi-gloss powder paint.
Read More
Read Less
Compliance Listing BAA and BABA
Product Type Pole
Primary Material Aluminum
Pole Height 10, 12, 14, 15, 16, 18, 20, 25, 30, 32, 35, 8
Pole Shaft Shape Square
Pole Shaft Style Straight
Anchor Bolt Circle Dia. 11, 12.5, 9
Architectural Style Utility
Series SSA

  • Suggested Replacement Products

PRODUCT INFORMATION

  • Spec Sheets

    Document Type Document Title Description Updated View
    Spec Sheet SSA_AOSSA_.pdf Holophane Square Straight Aluminum (SSA) Pole 5/20/2024 View

  • Photometry & Revit (BIM)

    CLICK HERE to start your request for a BIM Model or IES file.

  • Spectral Data Sheets

  • Guideline Specifications

  • Revit Component Files (Non-Illuminated)

  • Technical Documents (e.g. Instruction Sheets, MSDS, CAD)

    Document Type Document Title Description Updated View
    Installation Instructions IN-459.pdf Direct Burial Base Installation Instructions 6/22/2023 View
    Templates TMP41.pdf Bolt Circle Template 3/17/2021 View
    Templates TMP45.pdf TMP 45 Bolt Circle Template 2/10/2021 View
    Templates TMP-48.pdf Bolt Circle Template 3/17/2021 View
